If you need clearance from all sides, this is your best bet. Must be used with an MSD 6, 7 or 8-series ignition.
Proven performance features include a high output magnetic pick-up and precision machined reluctor for accurate ignition triggering. A fully adjustable mechanical advance allows you to tailor the advance curve to your specific application. Topping it all off is our own small diameter cap. This is molded out of durable Rynite® material and comes with an optional wire retainer.
Proven performance features include a high output magnetic pick-up and precision machined reluctor for accurate ignition triggering. A fully adjustable mechanical advance allows you to tailor the advance curve to your specific application. Topping it all off is our own small diameter cap. This is molded out of durable Rynite® material and comes with an optional wire retainer.
- Advance weight pins are staked and tig welded to the plate
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing and extra long sintered bushing
- O-ring seals can be added to modified blocks to improve oil pressure control• Must be used with an MSD 6, 7, 8, or 10 Series Ignition
- No CARB Exemption Order Number
- CNC machined billet aluminum housing is 3/8” smaller in diameter and 7/8” shorter than conventional Chevy V-8 distributors with the “points” type cap
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Mechanical advance assembly can be locked out for crank trigger systems
- Adjustable slip collar mounting flange for engines with modified deck heights
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Supplied with small diameter HEI style distributor cap and rotor (will accept 8441 Cap-A-Dapt)
- Nylon pads ensure smooth operation of the advance weights
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Special oil tract improves lubrication to the distributor and cam gear
- Will not accept a vacuum advance canister
Application Summary:
| Year | Make/Model |
|---|---|
| 1955-1975 | Chevrolet Bel Air |
| 1981 | Chevrolet Bel Air |
| 1958-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1987-1994 | Chevrolet Blazer |
| 1958-1961 | Chevrolet Brookwood |
| 1969-1972 | Chevrolet Brookwood |
| 1975-1986 | Chevrolet C10 |
| 1960-1974 | Chevrolet C10 Pickup |
| 1967-1986 | Chevrolet C10 Suburban |
| 1982-1985 | Chevrolet C15 |
| 1988-1999 | Chevrolet C1500 |
| 1992-1999 | Chevrolet C1500 Suburban |
| 1975-1987 | Chevrolet C20 |
| 1960-1974 | Chevrolet C20 Pickup |
| 1967-1986 | Chevrolet C20 Suburban |
| 1988-2000 | Chevrolet C2500 |
| 1992-1999 | Chevrolet C2500 Suburban |
| 1975-1986 | Chevrolet C30 |
| 1966 | Chevrolet C30 Panel |
| 1960-1974 | Chevrolet C30 Pickup |
| 1983-2000 | Chevrolet C35 |
| 1988-2000 | Chevrolet C3500 |
| 1960-1962 | Chevrolet C40 |
| 1967-1992 | Chevrolet Camaro |
| 1966-1996 | Chevrolet Caprice |
| 1964-1977 | Chevrolet Chevelle |
| 1963-1968 | Chevrolet Chevy II |
| 1955-1982 | Chevrolet Corvette |
| 1984-1992 | Chevrolet Corvette |
| 1957-1958 | Chevrolet Del Ray |
| 1959-1960 | Chevrolet El Camino |
| 1964-1987 | Chevrolet El Camino |
| 1969-1970 | Chevrolet Estate |
| 1996-2002 | Chevrolet Express 1500 |
| 1996-2002 | Chevrolet Express 2500 |
| 1996-2002 | Chevrolet Express 3500 |
| 1975-1995 | Chevrolet G10 |
| 1968-1974 | Chevrolet G10 Van |
| 1975-1995 | Chevrolet G20 |
| 1967-1974 | Chevrolet G20 Van |
| 1975-1996 | Chevrolet G30 |
| 1970-1974 | Chevrolet G30 Van |
| 1958-1985 | Chevrolet Impala |
| 1994-1996 | Chevrolet Impala |
| 1975-1986 | Chevrolet K10 |
| 1960-1974 | Chevrolet K10 Pickup |
| 1967-1986 | Chevrolet K10 Suburban |
| 1988-1999 | Chevrolet K1500 |
| 1992-1999 | Chevrolet K1500 Suburban |
| 1975-1986 | Chevrolet K20 |
| 1967 | Chevrolet K20 Panel |
| 1960-1974 | Chevrolet K20 Pickup |
| 1967-1986 | Chevrolet K20 Suburban |
| 1988-2000 | Chevrolet K2500 |
| 1992-1999 | Chevrolet K2500 Suburban |
| 1977-1986 | Chevrolet K30 |
| 1968-1974 | Chevrolet K30 Pickup |
| 1988-2000 | Chevrolet K3500 |
| 1975-1986 | Chevrolet K5 Blazer |
| 1959-1961 | Chevrolet Kingswood |
| 1969-1972 | Chevrolet Kingswood |
| 1975 | Chevrolet Malibu |
| 1978-1983 | Chevrolet Malibu |
| 1970-1988 | Chevrolet Monte Carlo |
| 1976-1979 | Chevrolet Monza |
| 1958-1961 | Chevrolet Nomad |
| 1969-1979 | Chevrolet Nova |
| Attributes | |
| ASIN | B000BYE7ZE |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-39 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Magnetic Pickup, Magnetic Pickup |
| Emission Code | 1, 1, Legal US |
| Engine Make/Size | Chevy Big Block (396-454), Chevy Small Block (262-400) |
| Gear Material | Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Product Type | Distributor, Distributor |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132085705 |
