Marine UL-Certified
The Marine Pro-Billet Distributors have been tested by Underwriter's Laboratory and are certified to meet or exceed safety standards for marine ignition systems as set by the U.S. Coast Guard.
The Marine Pro-Billet Distributors have been tested by Underwriter's Laboratory and are certified to meet or exceed safety standards for marine ignition systems as set by the U.S. Coast Guard.
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Must be used with an MSD Ignition Control
- Special oil tract improves lubrication to the distributor and cam gear
- Nylon pads ensure smooth operation of the advance weights
- Supplied with a bolt down HEI style distributor cap and rotor
- Mechanical advance assembly can be locked out for crank trigger systems
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing and extra long sintered bushing
- Designed for use in marine applications with Chevy V8 automotive engines
- O-ring seals can be added to modified blocks to improve oil pressure control
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Will not accept a vacuum advance canister
- Advance weight pins are staked and tig welded to the plate
- UL Approved
- Weathertight connectors are used for locked and sealed connections
- CNC machined billet aluminum housing and billet aluminum base with two flame arrestor holes with brass screens
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
Application Summary:
| Year | Make/Model |
|---|---|
| 1955-1975 | Chevrolet Bel Air |
| 1981 | Chevrolet Bel Air |
| 1958-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1987-1994 | Chevrolet Blazer |
| 1958-1961 | Chevrolet Brookwood |
| 1969-1972 | Chevrolet Brookwood |
| 1975-1986 | Chevrolet C10 |
| 1960-1974 | Chevrolet C10 Pickup |
| 1967-1986 | Chevrolet C10 Suburban |
| 1982-1985 | Chevrolet C15 |
| 1988-1999 | Chevrolet C1500 |
| 1992-1999 | Chevrolet C1500 Suburban |
| 1975-1987 | Chevrolet C20 |
| 1960-1974 | Chevrolet C20 Pickup |
| 1967-1986 | Chevrolet C20 Suburban |
| 1988-2000 | Chevrolet C2500 |
| 1992-1999 | Chevrolet C2500 Suburban |
| 1975-1986 | Chevrolet C30 |
| 1966 | Chevrolet C30 Panel |
| 1960-1974 | Chevrolet C30 Pickup |
| 1983-2000 | Chevrolet C35 |
| 1988-2000 | Chevrolet C3500 |
| 1960-1962 | Chevrolet C40 |
| 1967-1992 | Chevrolet Camaro |
| 1966-1996 | Chevrolet Caprice |
| 1964-1977 | Chevrolet Chevelle |
| 1963-1968 | Chevrolet Chevy II |
| 1955-1982 | Chevrolet Corvette |
| 1984-1992 | Chevrolet Corvette |
| 1957-1958 | Chevrolet Del Ray |
| 1959-1960 | Chevrolet El Camino |
| 1964-1987 | Chevrolet El Camino |
| 1969-1970 | Chevrolet Estate |
| 1996-2002 | Chevrolet Express 1500 |
| 1996-2002 | Chevrolet Express 2500 |
| 1996-2002 | Chevrolet Express 3500 |
| 1975-1995 | Chevrolet G10 |
| 1968-1974 | Chevrolet G10 Van |
| 1975-1995 | Chevrolet G20 |
| 1967-1974 | Chevrolet G20 Van |
| 1975-1996 | Chevrolet G30 |
| 1970-1974 | Chevrolet G30 Van |
| 1958-1985 | Chevrolet Impala |
| 1994-1996 | Chevrolet Impala |
| 1975-1986 | Chevrolet K10 |
| 1960-1974 | Chevrolet K10 Pickup |
| 1967-1986 | Chevrolet K10 Suburban |
| 1988-1999 | Chevrolet K1500 |
| 1992-1999 | Chevrolet K1500 Suburban |
| 1975-1986 | Chevrolet K20 |
| 1967 | Chevrolet K20 Panel |
| 1960-1974 | Chevrolet K20 Pickup |
| 1967-1986 | Chevrolet K20 Suburban |
| 1988-2000 | Chevrolet K2500 |
| 1992-1999 | Chevrolet K2500 Suburban |
| 1977-1986 | Chevrolet K30 |
| 1968-1974 | Chevrolet K30 Pickup |
| 1988-2000 | Chevrolet K3500 |
| 1975-1986 | Chevrolet K5 Blazer |
| 1959-1961 | Chevrolet Kingswood |
| 1969-1972 | Chevrolet Kingswood |
| 1975 | Chevrolet Malibu |
| 1978-1983 | Chevrolet Malibu |
| 1970-1988 | Chevrolet Monte Carlo |
| 1976-1979 | Chevrolet Monza |
| 1958-1961 | Chevrolet Nomad |
| 1969-1979 | Chevrolet Nova |
| Attributes | |
| ASIN | B00062YZ30 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Magnetic Pickup, Magnetic Pickup |
| Emission Code | 3, 3, Off Road |
| Engine Make/Size | Chevy Marine V8 |
| Gear Material | Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type | Marine |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| part type | Distributor, Distributor |
| Product Type | Distributor, Distributor |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| GTIN | 00085132085606 |
