GM Gen V LT Swap Oil Pan - Black - with Turbo Oil or PVC Return Port
These oil pans are perfect for: 1967-1992 Camaro/Firebird, 1968-1974 Nova/Apollo/Ventura/Omega, 1978-1987 G-body, 1964-1972 A-body, and 1973-1987 Chevy/GMC Full Size Trucks.
These oil pans are perfect for: 1967-1992 Camaro/Firebird, 1968-1974 Nova/Apollo/Ventura/Omega, 1978-1987 G-body, 1964-1972 A-body, and 1973-1987 Chevy/GMC Full Size Trucks.
- Designed for LT Engine Swap Installations in Classic Car and Truck Chassis Requiring More Oil Pan to Chassis Clearance Around the Front Half of the Oil Pan
- Cast and machined aluminum
- 1/2” NPT port – Ideal for Turbo Oil Return or PCV Oil Return
- Optional Hinge Door Baffle - Available Separately
- Complete Kit Includes: Windage Tray, Sump Baffle, OE Style Pick-Up Tube, Sump Port Plug, Oil Filter Stud, Billet Oil Passage Cover, etc.
- Allows for up to 4.00” Crankshaft Stroke
- Can Be Used Anywhere a GM F-Body Oil Pan Can Be Used
- Provides OE Style fitment - OE oil filter mounting, OE oil cooler port provision, OE engine NVH suppression, OE flange gasket and sealing, proper structural rigidity and OE bell-housing attachments
- Traditional High-Quality Cast Aluminum Appearance With Clean Exterior Styling
- Provides Maximum Clearance for Vehicles Where the Steering Linkage is Behind the Engine cross-member
- Oil cooler port provision
Information:
Maximum Recommended Crankshaft Stroke 4.00". This oil pan is not for use on engines that originally used a dry sump oiling system. Recommended LT Dipstick & Dipstick Tube - GM part #s 12661062 (dipstick) and 12678823 (dipstick tube) Some factory LT1 applications include an oil temperature sensor. Currently this pan does not have a boss to install that temperature sensor. If the sensor is desired, it will have to be relocated and machining would be required.Application Summary:
| Year | Make/Model |
|---|---|
| 1978-1987 | Buick Regal |
| 1973-1974 | Chevrolet Blazer |
| 1975-1986 | Chevrolet C10 |
| 1963-1974 | Chevrolet C10 Pickup |
| 1973-1986 | Chevrolet C10 Suburban |
| 1982-1988 | Chevrolet C15 |
| 1988-1998 | Chevrolet C1500 |
| 1979-1987 | Chevrolet C20 |
| 1979-1986 | Chevrolet C20 Suburban |
| 1967-1969 | Chevrolet Camaro |
| 1968 | Chevrolet Chevy II |
| 1978-1987 | Chevrolet El Camino |
| 1975-1986 | Chevrolet K10 |
| 1973-1974 | Chevrolet K10 Pickup |
| 1988-1998 | Chevrolet K1500 |
| 1975-1982 | Chevrolet K5 Blazer |
| 1978-1983 | Chevrolet Malibu |
| 1978-1988 | Chevrolet Monte Carlo |
| 1969-1972 | Chevrolet Nova |
| 1987 | Chevrolet R10 |
| 1987-1988 | Chevrolet R10 Suburban |
| 1987-1988 | Chevrolet R20 Suburban |
| 1987 | Chevrolet V10 |
| 1975-1978 | GMC C15 |
| 1967-1974 | GMC C15/C1500 Pickup |
| 1973-1974 | GMC C15/C1500 Suburban |
| 1988-1999 | GMC C1500 |
| 1979-1986 | GMC C1500 Suburban |
| 1979-1986 | GMC C2500 |
| 1979-1986 | GMC C2500 Suburban |
| 1978-1987 | GMC Caballero |
| 1973-1982 | GMC Jimmy |
| 1975-1978 | GMC K15 |
| 1973-1974 | GMC K15/K1500 Pickup |
| 1988-1999 | GMC K1500 |
| 1987 | GMC R1500 |
| 1987 | GMC R1500 Suburban |
| 1987 | GMC R2500 |
| 1987 | GMC R2500 Suburban |
| 1997-2006 | Jeep TJ |
| 1987-1995 | Jeep Wrangler |
| 1997-2006 | Jeep Wrangler |
| 1978-1981 | Oldsmobile Cutlass |
| 1985-1988 | Oldsmobile Cutlass |
| 1978-1984 | Oldsmobile Cutlass Calais |
| 1980-1983 | Oldsmobile Cutlass Cruiser |
| 1978-1980 | Oldsmobile Cutlass Salon |
| 1985-1987 | Oldsmobile Cutlass Salon |
| 1978-1988 | Oldsmobile Cutlass Supreme |
| 1968-1971 | Pontiac Acadian |
| 1978-1986 | Pontiac Bonneville |
| 1967-1969 | Pontiac Firebird |
| 1978-1987 | Pontiac Grand Prix |
| 1971-1972 | Pontiac Ventura |
| Attributes | |
| Application | GM Gen V LT |
| Baffled | No |
| Brand | Holley, Holley |
| California Proposition 65 | No |
| Capacity | 6.1 |
| Category | Oil Pans, Engine |
| Category Filter | Oil Pans |
| Clearance Category | Oil Pans |
| Color | Black |
| Country of Origin (Primary) | CN |
| Crank Shaft Wiper Included | No |
| Dipstick Port | No |
| Drain Plug Included | Yes |
| Emission Code | 5, 6 |
| Engine | GM Gen V (LT), GM Gen V (LT) |
| Engine Make/Size | Chevy Gen V |
| Finish | Black |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409910000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum |
| Maximum Stroke | 4.00", 4.00" |
| NAFTA Preference Criterion Code | B |
| Oil Pan Capacity | 6.1 Quarts, 6.1 Quarts |
| Oil Pan Type | Cast, Cast |
| Oil Return Size | 1/2" NPT, 1/2" NPT |
| part type | Engine Oil Pan |
| Pickup Included | Yes |
| Product Type | Oil Pan Kit, Oil Pan Kit |
| Sale Category | Engine |
| SDR Required Flag | N |
| Sub Category | Cylinder Block Components |
| Sump Location | Rear |
| Sump Type | Wet |
| Turbo Oil Drainback | Yes, Yes |
| Usage | Street/Performance |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Windage Tray Included | Yes |
| GTIN | 00090127140772 |
