Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing Ford truck headers decades. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your exhaust system to bolt up to these SB Ford, Ranger swap headers, even if it is not perfectly aligned with the header collectors.
These BLACK-MAXX coated, MID-LENGTH TUBE headers are designed specifically for swapping a Ford Small Block 260-302W engine into a 1982-1997 Ford Ranger 2WD (only) truck. These headers fit both automatic and manual, floor-shift transmissions. The smooth 1-1/2 in. tube design provides good exhaust flow to let your Ford Windsor Block engine breathe better, and produce excellent low-end torque and horsepower.
Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.
Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty. These headers have a high temperature, SATIN-BLACK ceramic finish that resists corrosion, and can withstand temperatures up to 1400 degree F. This finish is covered by a 5-year factory warranty, in addition to Hedman's standard lifetime header warranty.
- Handcrafted, Mild Steel Construction.
- The Mid-Length Tube Header Design Provides Significantly More Low and Mid-range Power than Cast Manifolds, and Provide Better Ground Clearance And Component Compatibility Than Long Tube Headers.
- Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
- Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
- Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
- Proud To Say, Made In The USA, Since 1954!
| Attributes | |
| Air Conditioning | Yes, Yes, Yes |
| Application | Automotive |
| Automatic Transmission - Column | No, No, No |
| Automatic Transmission - Floor | Yes, Yes, Yes |
| Bolts/Studs Included | Yes, Yes, Yes |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included | NO, No, No |
| Coating/Finish | Satin Black Ceramic |
| Collector Attachment | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Collector Bolts Included | Yes, Yes, Yes |
| Collector Diameter | 2-1/2 in., 2-1/2 in. |
| Collector Size | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Collector Style | Ball and Socket Style (Gasketless), BALL and SOCKET Style (Gasketless), BALL and SOCKET Style (Gasketless) |
| Collector Tube Size (in.) | 2.5 |
| Contents | headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware |
| Country of Origin (Primary) | US |
| Crossover Pipe Included | NO, No, No |
| Cylinder Head | Stock Profile Heads, Stock Profile Heads, Stock Profile Heads |
| Cylinder Head Port Shape | Square, Square, Square |
| Drivetrain | 2WD |
| E.O. # | No, No |
| Emission Code | Not in CA |
| Emissions Notes | NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., Not Legal For Street Use on '75-Later Model Years! Legal for off-road use only. |
| Engine Make/Size | Ford 260-302 |
| Engine Version | Ford Windsor Block (W), Ford Windsor Block (W), Ford Windsor Block (W) |
| Exhaust System Dia | 2 in., 2-1/2", 2-1/2 in. |
| Finish | BLACK MAXX Satin Black Ceramic-Metallic, BLACK MAXX Satin Black Ceramic-Metallic |
| Finish Type | BLACK MAXX- Black Ceramic-Metallic Coating, BLACK MAXX- Black Ceramic-Metallic Coating, BLACK MAXX- Black Ceramic-Metallic Coating |
| Flange Style | Standard, Standard, Standard |
| Flange Thickness | 0.25", 0.3125 in., 1/4 in. with 5/16 in. collector ring flange. |
| Gasket # | 27340 |
| Gasket Or Seal Included | Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) | 8708925000 |
| Hazardous Material Code | N |
| Head Flange Gasket | 27340 |
| Header Construction | Standard-Duty, MILD STEEL- Standard-Duty |
| Header Fasteners Included | Yes, Yes |
| Header Finish | BLACK MAXX Satin Black Ceramic-Metallic, BLACK MAXX Satin Black Ceramic-Metallic, BLACK MAXX Satin Black Ceramic-Metallic |
| Header Material | Mild Steel, Mild Steel, Mild Steel |
| Header Port Shape | Square, Square, Square |
| Header Style | Mid-Length Tube, Engine Swap |
| Installation Hardware Included | Yes, Yes, Yes |
| Life Cycle Status Code | Available to Order |
| Manual Transmission - Column | No, No, No |
| Manual Transmission - Floor | Yes, Yes, Yes |
| Material | Mild Steel, Mild Steel |
| Motor Mounts (Included) | NO, No |
| Motor Mounts Included | NO, No, No |
| Mounting Hardware Included | Yes, Yes, Yes |
| NAFTA Preference Criterion Code | B |
| Notes | 82-97 Ford Ranger V8 Swap 2WD 260-302, 82-97 Ford Ranger V8 Swap 2WD 260-302, 82-97 Ford Ranger V8 Swap 2WD 260-302 |
| Package Contents | One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Port Shape | Square, Square, Square |
| Power Steering | Yes, Yes, Yes |
| Primary Tube Diameter (in) | 1.50", 1.50 in., 1.50 in. |
| Primary Tube Gauge | 18g, 16g, 16g |
| Product Info | Not for use with Smog Injection or Injection Heads, Not for use with Smog Injection or Injection Heads, Not for use with Smog Injection or Injection Heads |
| Quantity | Sold as a pair., Sold as a pair., Sold as a pair. |
| Reducer Outlet Size | 2-1/2", 2 in., 2-1/2 in. |
| Reducers Included | Yes, Yes, Yes |
| Replacement Gasket | 27340, 27340, 27340 |
| Replacement Head Flange Gasket | 27340, 27340 |
| SDR Required Flag | N |
| Transmission Mount Included | NO |
| Transmission Mount/Crossmember (Included) | No, No |
| Transmission Mount/Crossmember Included | No |
| Tube Design | SHORT TUBE, SHORT TUBES, MID-LENGTH, Standard |
| Tube Diameter | 1-1/2 in., 1-1/2" |
| Tube Direction | Down Swept |
| Tube Length | MID-LENGTH Tubes, Mid-Length Tubes |
| Tube Material Thickness | 18g, 16g, 16g |
| Tube Size | 1-1/2", 1-1/2 in., 1-1/2 in. |
| Tube Style | Mid-Length, Mid-Length |
| Tuned | NO, No, No |
| Variations | 89500, 89508, 89500, 89508, 89500, 89508 |
| Weld-Up | No, No, No |
| with A.I.R. | No |
| with A.I.R. System | No, No, No |
| with EGR | No, No, No |
| Y-Pipe Included | No, No, No |
| GTIN | 00732611895033 |
